Features:
Equipped with a 7-inch LCD screen
This series comes standard with a 7-inch LED display, offering clear visuals and more convenient operation. It can meet a wider range of non-standard modification requirements.
Trend chart function,
Running data USB export function(in CSV format) is available.
Can achieve the non- overshoot control
PID with overshoot control can be within 2 ℃, the overshoot suppression function can achieve the non- overshoot control.
Calculate and control the fluctuation of each point within 0.5 ℃ according to GB/T 5170.
Higher temperature indication resolution
Increase the resolution of indication control to 0.1 ℃.
Segmentation deviation correction function, user single point correction, manufacturer 9 point segmented correction is available.
Can meet more non-standard renovation requirements
By expanding the PLC controller module, more non-standard modification requirements can be met.
Various hardware such as detection points, output points, and analog output can be modified according to the needs.
Adopting the idea of modular program editing, the theoretical programming capacity of PID is 32 set, which can achieve modification of multi chamber combination, and transform from N (controller)+N (inner box) to 1 (controller)+N (inner box), Each box can achieve independent temperature control.
SPECIFICATIONS
※The temperature chamber's performance values are based on GB/T5170.2,and IEC60068-3-5.And humidity chamber's performance values are based on GB/T5170.5 and IEC60068-3-6.Performance figures aregiven for a +23℃ ambient temperature, relative humidity 65±20% RH, rated voltage, with no specimens inside the test area.
